Distribution Transformer

Distribution transformers are critical components in electrical power distribution systems, responsible for stepping down high-voltage electricity from power plants and transmission lines to lower voltages suitable for residential, commercial, and industrial use. Here's a comprehensive introduction to the category of distribution transformers, including their types, features, and applications:

Types of Distribution Transformers

1. Single Phase Distribution transformer:

   • Ideal for lower capacity applications such as residential complexes and commercial buildings. Common ratings include 10 kVA, 25 kVA, and 63 kVA.

2. Three-Phase Distribution Transformer:

   • Used for higher capacities in industrial setups and large residential complexes. Common ratings range from 25 kVA to 500 kVA, with specific models like 100 kVA, 160 kVA, 200 kVA, 315 kVA, and 500 kVA catering to various power demands.

Salient Features of Distribution Transformers

1. High Efficiency:

   • Modern distribution transformers boast high efficiency rates of over 97%, ensuring minimal energy loss during power transfer.

2. Reliability:

   • They are designed with stringent quality control standards, ensuring reliable service for over 25 years.

3. Overload Capability:

   • They can handle short-term overloads above the rated capacity to accommodate occasional spikes in power demand.

4. Protection Features:

   • Equipped with inbuilt devices to protect against overheating, voltage spikes, and short circuits.

5. Minimal Maintenance:

   • Robust sealed tanks with long-life insulating oil reduce maintenance requirements.

6. Compact Footprint:

   • Pole-mounted transformers utilize minimal ground space, making them suitable for areas with limited availability of land.

7. Low Environmental Impact:

   • Many distribution transformers use non-toxic, biodegradable vegetable-based oil instead of mineral oils.

Applications of Distribution Transformers

1. Step Down Voltages:

   • They reduce high transmission voltages of 33kV or 66kV down to primary distribution voltages of 11kV or 22kV and further down to 400/230V suitable for final consumers.

2. Interface in Distribution Systems:

   • Serve as the interface between various sections of the distribution system with different voltage levels.

3. Electric Railway Systems:

   • Provide ideal voltages to supply electric railway systems.

4. Agricultural Areas:

   • Supply power to agricultural areas located away from the main grid.

5. Temporary Loads:

   • Cater to temporary loads on construction sites.

Ensuring Quality and Reliability

Distribution transformers are subject to rigorous testing to meet international standards, ensuring no-load and full-load losses stay within prescribed limits, impedance voltage values are correct, temperature rise is within safe levels, and short circuit withstand capability meets stipulations.

In conclusion, distribution transformers are indispensable in the power distribution infrastructure, ensuring that electricity reaches end-users safely and efficiently. Their diverse types, unique features, and wide range of applications make them a cornerstone of modern electrical systems.
