S20/S22 Series Dry Type Three-Phase Transformer: Pioneering Energy Efficiency and Environmental Stewardship

Transformer is a device that uses the principle of electromagnetic induction to change AC voltage. Its main components are primary coil, secondary coil and iron core (magnetic core). Its main functions include voltage conversion, current conversion, impedance conversion, isolation, voltage stabilization (magnetic saturation transformer), etc. Classification by insulation and cooling method. Transformers can be divided into oil-immersed, dry-type and gas-insulated types according to insulation and cooling methods. Among them, oil-immersed transformers include oil-immersed self-cooling type, oil-immersed air-cooling type, oil-immersed water-cooling type and forced oil circulation cooling type. Oil-immersed Power Transformers have been widely used because of their advantages of good heat dissipation, low loss, large capacity and low price. The S20 and S22 series of eco-friendly oil-immersed transformers are designed to meet the growing demands for energy efficiency and environmental sustainability in power distribution systems. Each series builds on the previous one, offering progressively better energy efficiency and sustainability features, making them ideal for modern power infrastructure.

S20 Series Oil-Filled Transformer

Key Features

Energy Efficiency: Continues the trend of improved efficiency with advanced design features that minimize energy loss and optimize performance.

Structural Design: Features a fully sealed structure that ensures minimal environmental impact and long-term reliability.

Regulatory Compliance: Manufactured in strict adherence to IEC 60076 and GB1094, ensuring compliance with the highest industry benchmarks.

Core Material: Utilizes high-quality cold-rolled grain-oriented silicon steel sheets, known for their excellent magnetic properties and low core losses.

Winding Configuration: The low-voltage winding is designed for compactness and strength, reducing radial forces during short circuits and enhancing the transformer's resilience.

Applications

Power generation facilities for efficient energy production.

Electrical transmission networks for reliable power distribution.

Petrochemical industries for stable power supply.

Metallurgical plants for demanding power requirements.

Industrial and mining enterprises for continuous operations.

Urban infrastructure projects, including airports, subways, docks, and residential areas, for sustainable power solutions.

S22 Series Oil-Filled Transformer

Key Features

Energy Efficiency: Represents the pinnacle of energy efficiency in the series, with the lowest no-load losses and high overall efficiency, making it one of the most energy-efficient transformers available.

Structural Design: Features an effective cooling system, such as oil circulation or natural convection, to maintain ideal operating temperatures and prevent overheating.

Regulatory Compliance: Manufactured in strict adherence to IEC 60076 and GB1094, ensuring compliance with the highest industry benchmarks.

Core Material: Utilizes high-quality cold-rolled grain-oriented silicon steel sheets, known for their excellent magnetic properties and low core losses.

Winding Configuration: The low-voltage winding is designed for compactness and strength, reducing radial forces during short circuits and enhancing the transformer's resilience.

Eco-friendly Insulating Oils: Prioritizes eco-friendly practices by using biodegradable insulating oils and materials with minimal environmental impact.

Applications

Power generation facilities for efficient energy production.

Electrical transmission networks for reliable power distribution.

Petrochemical industries for stable power supply.

Metallurgical plants for demanding power requirements.

Industrial and mining enterprises for continuous operations.

Urban infrastructure projects, including airports, subways, docks, and residential areas, for sustainable power solutions.

Environmental Features

Biodegradable Insulating Oils: The S22 series prioritizes eco-friendly practices by using biodegradable insulating oils and materials with minimal environmental impact.

High Biodegradability: The insulating oils used in these transformers are highly biodegradable, minimizing environmental pollution in the event of an oil leakage accident.

Fire Safety: The use of natural ester oils provides excellent fire safety credentials, reducing the risk of fire and explosion.

Extended Transformer Life: Higher water saturation compared to mineral oil reduces insulation moisture content, leading to a longer transformer life.

Performance Advantages

Economic Performance: Offers a superior balance between technical performance and economic viability, making it a cost-effective solution for power distribution.

Extended Lifespan: Designed for longevity, ensuring a prolonged service life with minimal maintenance, reducing the total cost of ownership.

Operational Reliability: Guarantees high levels of operational dependability, contributing to the stability and reliability of the power grid.

Space Optimization: Designed to occupy minimal space, optimizing spatial utilization in power distribution facilities, particularly beneficial in urban and constrained environments.

Conclusion

The S20 and S22 series of eco-friendly oil-immersed transformers are not just a testament to innovation in power distribution technology; they represent a commitment to environmental responsibility and economic efficiency. Setting a new standard for performance and sustainability in the power industry, these transformers provide a reliable and efficient solution for modern power needs, ensuring a greener and more reliable future for power infrastructure.

10kV Oil Immersed Distribution Transformer energy efficiency grade table
