American substations are critical components of the electrical power infrastructure, responsible for transforming voltage levels and managing the flow of electricity from generation to consumption. They are engineered to ensure the efficient and reliable distribution of power across the country. Here's an overview of the classifications and features of American substations:

1. Classification Based on Nature of Duties:

   • Step-Up or Primary Substations: These substations are typically associated with generating stations and are responsible for stepping up the generated voltage to a higher level suitable for long-distance transmission .
   • Primary Grid Substations: Located at load centers along primary transmission lines, these substations step down the primary transmission voltage to secondary voltages for further distribution .
   • Step-Down or Distribution Substations: Situated at load centers, these substations step down the sub-transmission/primary distribution voltage to secondary distribution voltage, which is then supplied to consumers .

2. Classification Based on Service Rendered:

   • Transformer Substations: These substations are equipped with transformers to change the voltage level as needed .
   • Switching Substations: Designed for switching operations between transmission lines without changing the voltage level .
   • Converting Substations: These substations are responsible for converting AC to DC or vice versa, or changing frequency levels .

3. Classification Based on Operating Voltage:

   • High Voltage Substations (HV Substations): Involving voltages between 11 kV and 66 kV .
   • Extra High Voltage Substations (EHV Substations): Involving voltages between 132 kV and 400 kV .
   • Ultra High Voltage Substations (UHV Substations): Operating on voltages above 400 kV .

4. Classification Based on Importance:

   • Grid Substations: Play a crucial role in transmitting bulk power across the grid, and any disturbance can affect the entire power supply .
   • Town Substations: Step down voltages for distribution within towns, and failures can lead to town-wide power outages .

5. Classification Based on Design:

   • Indoor Type Substations: Equipment is installed within a building, typically used for voltages up to 11 kV but can be used up to 66 kV in contaminated environments .
   • Outdoor Substations: Equipment is installed outdoors, suitable for higher voltages where the required space for equipment is substantial .

6. Classification Based on Constructional Features:

   • Pole Mounted Substations: Equipment is installed overhead on H-pole or 4-pole structures, typically for voltages not exceeding 11 kV .
   • Foundation Mounted Substations: For heavier transformers above 250 kVA, these substations are mounted on a foundation rather than poles .

7. Classification Based on Application/Service Requirements:

   • Transformer Substations: Change the voltage level of the electric supply .
   • Switching Substations: Control the flow of electrical power between different transmission lines or distribution networks .
   • Power Factor Correction Substations: Improve power factor to enhance energy efficiency .
   • Frequency Changer Substations: Convert frequency from higher to lower or vice versa .
   • Converting Substations: Convert AC power into DC power for specific applications such as traction, electroplating, and electric welding .

American substations are designed with a focus on reliability, safety, and efficiency, catering to the diverse needs of the power grid and ensuring the continuous supply of electricity to consumers.
