Compact Transformer Diagnostic Equipment

Get Latest Price

Contact Now

Brand: JUTAI

Place Of Origin: China

Use: Power, Current, Electronic, High Frequency, Instrument

Phase: Single, Three

Coil Structure: Toroidal

Number Of Coils: Autotransformer

Description

Product Description

Mobile Transformer Testing Equipment Product Description

HGKG-6 high-voltage switch dynamic characteristics tester is a special instrument developed by our company to meet the needs of on-site testing of high-voltage switch action characteristics. It uses a single-chip microcomputer as the core for sampling, processing and output. The main features of the instrument are that it uses Chinese characters to prompt the operation in a human-computer dialogue mode, and the results are displayed in Chinese characters and printed out. It has the advantages of intelligence, multiple functions, accurate data, strong anti-interference, simple operation, small size, light weight, and beautiful appearance. The high-voltage switch dynamic characteristics tester is suitable for dynamic characteristics testing of various indoor and outdoor switches with little oil, more oil, vacuum switches, and sulfur hexafluoride switches. The portable Transformer Measurement Instruments is a high-performance tool designed for on-site transformer testing, which can quickly and accurately evaluate the performance and health of the transformer.

Features:

Adopting precision bridge measurement technology, the ratio measurement accuracy is as high as ±0.1%.
The equipment is highly portable, suitable for on-site use, and can expand the measurement range.
The frequency response analysis method is used to detect the deformation of the transformer winding.
Applicable to transformers with voltage levels of 6kV and above.
Provide a stable and uniform temperature environment without the need for liquid media.
It is highly portable and suitable for on-site calibration work, and the temperature rises and falls quickly.
High-precision measurement of transformer short-circuit impedance, no-load loss, insulation resistance and other parameters.
Provide comprehensive data analysis and report generation functions.

Application scenarios:

Applicable to on-site testing of substations, power plants and industrial facilities.
Applicable to quality inspection of transformer manufacturers and on-site acceptance of power systems.
Used to evaluate whether the transformer winding is deformed due to short-circuit current or physical impact during operation or transportation.
Supports live or power-off testing, suitable for multiple brands of tap changers.

Technical Specifications:

Power Supply: Internal rechargeable battery or external AC power supply, compatible with 110-240V, 50/60Hz.
Test Voltage Range: 0 to 3000V for high-voltage testing.
Current Measurement Range: 0 to 60A for high-current testing.
Frequency Range: 25Hz to 2000Hz for advanced frequency response analysis.
Partial Discharge Sensitivity: As low as -100dBm.
Operating Temperature: -20°C to 60°C.
Humidity Tolerance: Up to 90% non-condensing.
Display: 12.1-inch high-resolution color touchscreen.
Battery Life: Up to 12 hours of continuous operation on a single charge.

Operational Highlights:

The Transformer Diagnostic Equipment can be operated standalone or integrated with a cloud-based platform for remote monitoring and data analysis.
It features a quick-change battery system, allowing for extended field operations without downtime.
The system includes a comprehensive set of accessories, such as test leads, probes, and adapters, for a wide range of transformer testing needs.

Conclusion: The Mobile Transformer Testing Equipment is a versatile and powerful diagnostic tool that meets the demands of modern electrical testing. Its combination of portability, advanced testing capabilities, and user-friendly operation makes it an indispensable tool for any professional involved in the maintenance, testing, and diagnosis of transformers.
