Transformer Field Test Kit

Overview: The Portable Transformer Diagnostic Equipment is a cutting-edge, field-ready diagnostic tool designed to simplify and expedite the testing process of transformers in various operational settings. This solution is tailored for electrical engineers and technicians who require a reliable, efficient, and easy-to-use testing system that delivers accurate results in real-world conditions.

Key Features:

1. Versatility and Mobility:

   • Engineered with a compact design, the solution is lightweight and easy to transport, making it ideal for field testing in remote or hard-to-reach locations.
   • The durable, weather-resistant casing ensures the equipment remains protected during transportation and in adverse weather conditions.

2. Comprehensive Testing Suite:

   • The solution encompasses a wide array of testing functions, including but not limited to bushing test, winding test, and core test, ensuring a thorough evaluation of the transformer's health.
   • It supports both AC and DC tests, catering to different transformer types and testing requirements.

3. User-Friendly Interface:

   • The system features an intuitive graphical user interface (GUI) with a large, backlit display for easy reading in all lighting conditions.
   • The menu-driven software provides step-by-step guidance through testing procedures, reducing the likelihood of user error.

4. High-Quality Measurements:

   • Utilizing precision measurement technology, the solution offers high-resolution data and accurate readings for reliable diagnostic results.
   • The system is calibrated to industry standards, ensuring that the measurements are consistent and repeatable.

5. Data Management and Reporting:

   • The Transformer Inspection Tools includes built-in data management capabilities, allowing for the storage, retrieval, and analysis of test results.
   • Reports can be generated on-site and exported in various formats, such as PDF and CSV, for easy integration with existing data management systems.

6. Safety and Compliance:

   • The solution is designed with safety in mind, incorporating features such as high-voltage insulation, overload protection, and automatic shutdown in case of fault detection.
   • It adheres to international safety standards and is certified for use in a variety of industrial and utility settings.

Technical Specifications:

• Power Source: Internal rechargeable battery or external AC power supply, 100-240V, 50/60Hz.
• Test Voltage Range: 0 to 2500V for high-voltage testing.
• Current Measurement Range: 0 to 30A for high-current testing.
• Frequency Range: 40Hz to 500Hz for advanced frequency response analysis.
• Partial Discharge Sensitivity: As low as -80dBm.
• Operating Temperature: -20°C to 60°C.
• Humidity Tolerance: Up to 95% non-condensing.
• Display: 12.1-inch high-resolution touchscreen.
• Communication Interfaces: USB, Wi-Fi, and Bluetooth for data transfer and remote operation.
• Battery Life: Up to 12 hours of continuous operation on a single charge.

Applications:

• Utility and Industrial Settings: Perfect for utility companies, industrial facilities, and power plants for routine maintenance and emergency diagnostics.
• Transformer Manufacturers: Useful for quality control and performance testing of new transformer models before deployment.
• Field Services: Essential for electrical contractors and service providers who need to perform on-site transformer testing.

Operational Highlights:

• The solution can be operated manually or integrated with a central monitoring system for remote diagnostics and predictive maintenance.
• It features a hot-swappable battery system, allowing for uninterrupted testing and extended field operations.
• The solution includes a comprehensive set of accessories, such as test leads, probes, and adapters, for a wide range of transformer testing needs.

Conclusion: The Portable Transformer Measurement Instruments is a robust and versatile diagnostic tool that meets the demands of modern electrical testing. Its combination of portability, advanced testing capabilities, and user-friendly operation makes it an indispensable tool for any professional involved in the maintenance, testing, and diagnosis of transformers.
