Go-anywhere Transformer Verification System

The Transformer Testing Equipment is a revolutionary portable diagnostic platform that provides unparalleled accuracy and ease of use for on-site transformer testing. The system is carefully designed to meet the needs of utility professionals, maintenance teams and electrical engineers to provide high-quality, reliable testing solutions for their transformers. The following is a detailed introduction to its features, advantages and application scenarios:

1. Precision Power Supply: The Transformer Diagnostic Equipment features an internal three-phase precision inverter power supply, which eliminates the harmonic interference from the mains voltage during measurement, ensuring more accurate results. When using a generator as the power source, there is no adverse impact.
2. Enhanced Testing Efficiency: Utilizing three-phase output voltage, the instrument significantly improves test speed. It can measure phase angles, automatically identify wiring groups from 0 to 11, and perform low-voltage measurements on multiple-winding rectifier transformers without disconnecting the low-voltage side. Additionally, it can measure the transformation ratio and 7.5° angle deviation.
3. Versatile Transformer Compatibility: The Transformer Inspection Tools is suitable for a wide range of transformers, including Z-type, rectifier, grounding, electric furnace, phase-shifting, and balancing transformers, making it ideal for various measurement applications.
4. Comprehensive Protection Mechanisms: The instrument includes high and low voltage reverse connection protection, transformer winding short-circuit protection, tap switch misalignment protection, and full output short-circuit protection, enhancing its stability and reliability.
5. Automated Measurement Capabilities: After entering the rated parameters, the instrument can automatically measure the transformer ratio, error value, and tap switch position. It is particularly effective for measuring the precise position of asymmetric tap switches, supporting up to 99 tap positions.
6. High-Definition Display: The instrument features a 7-inch HD color touchscreen LCD with modular display capabilities, ensuring clear visibility even in strong light conditions.
7. Flexible Data Output Options: The instrument supports both print output and USB interface, and can also be equipped with an RS232 interface, facilitating paperless office operations.
8. Durable and Portable Design: The instrument is housed in a cold and heat-resistant, sealed, waterproof, and shockproof multi-functional engineering plastic case, making it highly suitable for field testing.
