Supreme Low-voltage withdrawable switchgear

Product Description:

The GGJ Drawer-type Switchgear serves as a cornerstone in power distribution within a variety of environments, including power generation plants, substations, industrial and mining enterprises, and the power distribution centers of high-rise buildings (PC) as well as motor control centers (MCC). Designed for power distribution, centralized motor control, and reactive power compensation in power generation and supply systems, it operates with a rated working voltage of 660V and below, and a rated current of 4000A and below, at frequencies of 50-60Hz.

Application Fields:

This Drawer Switchgear finds extensive application in outdoor locations such as 6-10kV ring networks and terminal user facilities. It is well-suited for a range of settings, including industrial parks, residential areas, commercial centers, parks, stations, airports, ports, oil fields, and temporary facilities.

Technical Features:

1. Compact Structure: Capable of accommodating more functional units in a smaller space, thereby saving on user investment.
2. Strong Structural Universality: Offers flexible assembly with a modular unit of 25mm, allowing for any combination of various sizes of draw-out units to meet specific system design requirements.
3. Insulation Protection: Vertical busbars and outgoing lines are well-insulated, ensuring safe and reliable maintenance from behind the cabinet.
4. Mechanical Interlocking Mechanism: Features a unique mechanism that provides reliable positions for operation, testing, withdrawal, and isolation, enhancing safety and reliability.
5. Drawer Push-In Mechanism: Utilizes rolling bearings, offering strong interchangeability among drawers of the same specifications.
6. Combination Design: Allows for a free combination of drawer-type and fixed partition-type schemes, providing design flexibility.
7. Live Door Protection System: Ensures the safety of front cabinet maintenance with a reliable protection system.
8. Pole Outgoing Line Options: Offers the flexibility to choose between three-pole or four-pole outgoing lines as needed.

Product Advantages:

1. Compact Structure: For efficient space utilization.
2. Strong Structural Universality and Flexible Assembly: Adapts to various assembly configurations.
3. Good Insulation Protection: For vertical busbars and outgoing lines, ensuring safety.
4. Unique Mechanical Interlocking Mechanism: Enhances operational safety and reliability.
5. Strong Combination Design: Provides versatility in design and application.
6. Reliable Live Door Protection System: Safeguards during front-side maintenance procedures.

The GGJ Draw-Out Switchgear is an efficient and reliable solution for low-voltage switchgear applications, offering a blend of compactness, flexibility, and safety in power distribution systems.
