HXGN-12 Compact SF6 High Voltage Switchgear

Product Brief: XGN2-12 Fixed Metal Enclosed Switchgear

Product Synopsis: The XGN2-12 Fixed Metal Closed Switchgear is a next-generation solution for medium-voltage power distribution, engineered to deliver optimal safety, performance, and adaptability. This switchgear is designed to meet the evolving demands of modern electrical systems, providing a reliable backbone for energy management across various industries.

Technical Specifications:

• Rated Voltage: 12kV, catering to the needs of medium-voltage networks.
• Frequency: 50Hz, in line with the standard frequency of power grids.
• Rated Current: A range of current ratings to accommodate different load requirements.
• Short-Circuit Withstand Current: Up to 50kA for 4 seconds, ensuring protection during fault conditions.
• Peak Withstand Current: Capable of withstanding peak currents of up to 125kA.
• Protection Class: IP2X, safeguarding against the ingress of solid objects.
• Dimensions: Customizable to fit various installation spaces.
• Weight: Typically ranges from 800 to 1100kg, depending on the specific configuration.

Product Highlights:

• Metal-Enclosed Construction: Offers enhanced safety and protection against environmental factors.
• Modular Compartmentalization: Houses separate chambers for breakers, busbars, cables, and control equipment, enhancing safety and simplifying maintenance.
• Pressure Relief System: Includes a pressure relief system to manage internal pressure in the event of an internal fault.
• Mechanical Interlocking: Prevents unauthorized operation and ensures safe switching procedures.
• Circuit Breaker Compatibility: Compatible with various types of vacuum circuit breakers, offering flexibility in circuit protection.
• Isolation Switches: High-quality switches for reliable operation and safe maintenance.
• Efficient Busbar System: Features a top-mounted busbar system for optimal current distribution.
• Internal Illumination: Facilitates easier maintenance and inspection with built-in lighting.

Operational Environment:

• Ambient Temperature: Designed to operate in environments with an ambient temperature not exceeding 40°C.
• Altitude: Suitable for use up to 3000m above sea level.
• Atmospheric Conditions: Intended for use in clean, non-corrosive environments.
• Humidity: Capable of operating in high humidity conditions without performance degradation.

Storage and Transportation:

• Storage: Should be kept in its original packaging to maintain its integrity.
• Transportation: Requires protection from direct sunlight, rain, and extreme temperatures during transit.

Applications:

• Power Generation Facilities: For efficient power distribution and control.
• Transformer Stations: To manage the flow of electricity from power plants to local grids.
• Industrial and Mining Enterprises: To ensure reliable power supply in harsh and demanding environments.
• Commercial Buildings: To provide a stable power supply for commercial and office spaces.

Why Select XGN2-12:

• Standards Compliance: Adheres to international safety and performance standards.
• Versatility: Adaptable to a wide range of configurations and system requirements.
• Durability: Built to withstand harsh conditions and provide long-term reliability.
• Maintenance Friendly: Designed for ease of maintenance to extend the service life.

The XGN2-12 Fixed Metal-Enclosed Switchgear is a symbol of reliability and safety in medium-voltage power distribution, offering a comprehensive solution for the energy management needs of various industries. Its advanced features and robust design ensure that it meets the demanding requirements of today’s electrical infrastructure.
