GCS Low-Voltage Draw-Out Switchgear: A Frontier in Electrical Distribution

Product Description

The GCS type low-voltage Drawer-type Switchgear represents the newest generation of switchgear, designed and developed by a collaborative team to meet the precise requirements of industry authorities, a broad range of power users, and design units. It is tailored to fit the national conditions of our country and boasts high technical performance indicators, making it adaptable to the evolving needs of the power market. Having passed a stringent joint appraisal in Shanghai in July 1996, the product has been recognized and affirmed by manufacturing units and power-using departments. The Ministry of Electric Power Industry and the Ministry of Mechanical Industry have jointly issued the "Notice on the Promotion and Application of GCS Type Low-Voltage Draw-Out Switchgear" (document numbers AnShengYong (1997) No. 01 and JiZhong (1997) No. 01). The GCS low-voltage draw-out switchgear is now widely applied across various sectors, including power generation, petroleum, chemical, metallurgical, textile, communication, and construction industries, in their distribution systems. It is particularly suited for large power plants, communication hubs, and modern enterprises with high automation levels that require computer control, serving as a distribution device for three-phase AC systems with a frequency of 50(60)Hz, a rated working voltage of 380V(660V), and a rated current of 4000A and below, for power distribution, centralized motor control, and reactive power compensation.

Application Fields

The GCS low-voltage Drawer Switchgear is extensively used in outdoor environments such as 6-10kV ring networks and end-user facilities, including:

• Industrial parks
• Residential areas
• Commercial centers
• Parks
• Stations
• Airports
• Ports
• Oil fields
• Temporary facilities

Technical Features

• Enhanced Thermal Capacity: Reduces the additional temperature rise caused by the temperature rise of transfer components, affecting connectors, cable heads, and partition plates.
• Clear and Reliable Separation: Ensures that a fault in one unit does not affect the operation of other units, confining faults to the smallest possible range.
• Excellent Thermal Stability: Capable of withstanding the impact of short-circuit currents of 80/176kA.
• High Circuit Capacity: The MCC cabinet can accommodate up to 22 circuits per cabinet, fully considering the needs of large single-machine capacity power plants and automation electric door (machine) groups in the petrochemical industry.
• Sufficient Secondary Connectors: The drawer unit has a sufficient number of secondary connectors (32 pairs for units of 1 and above, 20 pairs for 1/2 units), meeting the requirements for the number of interface points for computer interfaces and automatic control circuits.

Product Advantages

1. Excellent Thermal Stability: Provides reliable operation under varying thermal conditions.
2. Clear Compartmentalization: Enhances safety by preventing faults from affecting multiple units.
