Superior XGN-12 Metal-Enclosed Switchgear

Technical Brochure: XGN2-12 Fixed Metal Enclosed Switchgear

Executive Summary: The XGN2-12 Fixed Metal Closed Switchgear is a high-performing medium-voltage switchgear system that combines advanced engineering with stringent safety protocols. It is tailored for applications where the secure and efficient distribution of electrical power is critical.

Key Technical Specifications:

• Voltage Rating: 12kV, catering to medium-voltage network requirements.
• Frequency: 50Hz, in synchronization with standard power grid frequencies.
• Rated Current: A variety of current ratings to accommodate diverse load specifications.
• Short-Circuit Withstand Current: Capable of withstanding up to 50kA for 4 seconds, ensuring safety during fault conditions.
• Peak Withstand Current: Able to handle peak currents up to 125kA.
• Protection Class: IP2X, safeguarding against the ingress of solid objects.
• Dimensions: Customizable to fit various installation spaces.
• Weight: Typically ranges from 800 to 1100kg, depending on the specific configuration.

Product Features and Benefits:

• Metal-Enclosed Structure: Provides superior safety and environmental protection for the internal components.
• Modular Design: Allows for customization and easy integration into existing electrical systems.
• Separate Compartments: Reduces the risk of electrical faults and facilitates maintenance with separate chambers for breakers, busbars, cables, and control units.
• Pressure Relief Channels: Safeguards against internal pressure buildup during fault conditions.
• Mechanical Interlocking: Ensures that the switchgear cannot be operated incorrectly, reducing the risk of accidents.
• Circuit Breaker Compatibility: Works with a range of vacuum circuit breakers for flexibility in circuit protection.
• Isolation Switches: Ensures reliable operation and safe maintenance.
• Top Busbar System: Optimizes current distribution for improved efficiency.
• Internal Illumination: Assists in maintenance and inspection tasks with built-in lighting.

Operational Parameters:

• Ambient Temperature: Designed to operate in environments with an ambient temperature not exceeding 40°C.
• Altitude: Suitable for use up to 3000m above sea level.
• Atmospheric Conditions: Intended for use in clean, non-corrosive environments.
• Humidity: Capable of operating in high humidity conditions without performance issues.

Storage and Transportation Guidelines:

• Storage: Should be stored in its original packaging to maintain product integrity.
• Transportation: Requires protection from direct sunlight, rain, and extreme temperatures during transit.

Diverse Applications:

• Power Generation Facilities: For efficient power distribution and control.
• Transformer Stations: To manage the flow of electricity from power plants to local grids.
• Industrial and Mining Enterprises: To ensure reliable power supply in harsh and demanding environments.
• Commercial Buildings: To provide a stable power supply for commercial and office spaces.

Why Choose XGN2-12:

• Standards Compliance: Adheres to international safety and performance standards.
• Versatility: Adaptable to a wide range of configurations and system requirements.
• Durability: Built to withstand harsh conditions and provide long-term reliability.
• Maintenance-Friendly Design: Engineered for easy maintenance to extend service life.

The XGN2-12 Fixed Metal-Enclosed Switchgear is a testament to the commitment to excellence in medium-voltage power distribution. It is a product that stands ready to serve the energy management needs of a diverse range of industries with its advanced features and robust design.
