XGN2-12 Metal-Enclosed Box Substation

Product Overview: XGN2-12 Fixed Metal Enclosed Switchgear

Introduction: The XGN2-12 Fixed Metal Closed Switchgear is a cutting-edge solution for medium-voltage electrical distribution, designed to provide exceptional safety, reliability, and operational efficiency. This switchgear is ideal for various applications, including industrial, commercial, and utility sectors, where robust power management is essential.

Key Technical Features:

• Rated Voltage: 12kV, suitable for medium-voltage applications.
• Frequency: 50Hz, compatible with standard electrical systems.
• Current Ratings: Available in multiple configurations to meet diverse load requirements.
• Short-Circuit Withstand Current: Up to 50kA for 4 seconds, ensuring protection during fault conditions.
• Peak Withstand Current: Capable of withstanding peak currents of up to 125kA.
• Protection Rating: IP2X, providing a high level of protection against solid objects.
• Dimensions: Customizable dimensions to fit specific installation requirements.
• Weight: Typically ranges from 800 to 1100kg, depending on configuration.

Innovative Design Features:

• Metal-Enclosed Structure: The robust metal enclosure enhances safety and protects internal components from environmental hazards.
• Compartmentalized Design: Separate compartments for circuit breakers, busbars, cables, and control devices to minimize the risk of electrical faults and improve maintenance access.
• Pressure Relief Mechanism: Designed with pressure relief channels to safely manage internal pressure during fault conditions.
• Mechanical Interlocking System: Prevents unauthorized operation and ensures safe switching procedures.
• Flexible Circuit Breaker Options: Compatible with various vacuum circuit breakers, allowing for tailored protection solutions.
• High-Quality Isolation Switches: Ensures reliable operation and safe maintenance practices.
• Efficient Busbar Arrangement: Features a top-mounted busbar system for optimal current distribution.
• Built-in Lighting: Internal illumination aids in maintenance and inspection tasks.

Operational Environment:

• Temperature Range: Designed to operate effectively in ambient temperatures up to 40°C.
• Altitude Capability: Suitable for operation at altitudes up to 3000m.
• Atmospheric Conditions: Intended for use in clean, non-corrosive environments.
• Humidity Tolerance: Can function in high humidity conditions without compromising performance.

Storage and Handling:

• Storage Requirements: Should be stored in its original packaging to maintain product integrity.
• Transportation Guidelines: Requires protection from direct sunlight, rain, and extreme temperatures during transport.

Applications:

• Power Generation Plants: For efficient power distribution and management.
• Substations: To facilitate the flow of electricity from generation sources to distribution networks.
• Industrial Facilities: Ensures reliable power supply in manufacturing and processing environments.
• Mining Operations: Provides robust power management solutions in challenging conditions.
• Commercial Buildings: Delivers stable power supply for various commercial applications.

Why Choose XGN2-12?

• Standards Compliance: Meets international safety and performance standards, ensuring reliability.
• Versatility: Adaptable to a wide range of configurations and system requirements.
• Durability: Built to withstand harsh conditions and provide long-term reliability.
• Maintenance-Friendly Design: Engineered for easy maintenance to extend service life.

The XGN2-12 Fixed Metal-Enclosed Switchgear represents a reliable and efficient solution for medium-voltage power distribution, making it an excellent choice for a variety of industrial and commercial applications. Its advanced features and robust design ensure that it meets the demanding requirements of today’s electrical infrastructure.
