New energy transformer oil tank

Get Latest Price

Contact Now

Brand: JUTAI

Place Of Origin: China

Use: Power, Current, Electronic, High Frequency, Instrument, Lighting

Phase: Three, Single

Coil Structure: Toroidal

Number Of Coils: Autotransformer

Description

Product Description

Transformer Parts Product Brief: Precision Transformer oil tank

Introduction: Optimize the performance and reliability of your electrical infrastructure with our Precision Transformer Oil Storage Tank. These Oil Immersed Transformer Tanks are designed with meticulous attention to detail, providing a robust and efficient housing for your transformers to ensure they operate at peak efficiency.

Main features of corrugated transformer oil tank

The corrugated Transformer Oil Storage Tank is a specially designed transformer enclosure with many unique features that give it superior performance compared to traditional tanks. Here are the main characteristics of the corrugated transformer tank:

1. Elastic Corrugated Structure

The core feature of the corrugated tank is its corrugated wall design. This design endows the tank with the ability to elastically deform, expanding and contracting in response to changes in the volume of the transformer oil, thereby compensating for volume changes.

Advantages:
- No need for an oil conservator: The tank compensates for oil volume changes through its own elasticity, eliminating the need for an additional conservator.
- Reduced risk of leakage: Without a conservator and related connecting components, the risk of leakage is significantly reduced.
- High adaptability: It can automatically adjust to changes in oil volume caused by temperature and load variations.

2. Fully Sealed Structure

The corrugated tank typically features a fully sealed design that effectively isolates the external air and moisture, preventing the oxidation and contamination of the transformer oil.

Advantages:
- Extended oil life: The sealed design reduces the oxidation rate of the oil, prolonging the oil replacement cycle.
- Improved insulation performance: By preventing the ingress of moisture and impurities, the insulation performance of the transformer is maintained.
- Reduced maintenance costs: With better sealing, maintenance work caused by oil degradation and leakage is minimized.

3. Good Heat Dissipation Performance

The corrugated structure of the tank not only provides elastic compensation but also increases the heat dissipation area, enhancing the cooling efficiency.

Advantages:
- Increased heat dissipation area: The corrugated design increases the surface area of the tank, improving heat dissipation.
- Suitable for high-load operation: Even under high-load or high-temperature conditions, the tank can effectively dissipate heat and ensure stable transformer operation.

4. Compact Size and Light Weight

Compared to traditional tanks, the corrugated tank is more compact in design, with a smaller volume and lighter weight.

Advantages:
- Space-saving: Suitable for installation in areas with limited space, such as urban substations or small distribution rooms.
- Easy transportation and installation: The lightweight design reduces transportation costs and installation difficulties.

5. Low Noise

The corrugated tank operates with low noise levels, meeting modern environmental requirements.

Advantages:
- Suitable for urban environments: The low-noise design makes it ideal for areas with strict noise regulations, such as urban settings.
- Reduced noise pollution: Provides a quieter environment for surrounding residents and working conditions.

6. High Reliability

The design and manufacturing processes of the corrugated tank ensure high mechanical strength and reliability.

Advantages:
- Good seismic performance: Capable of withstanding mechanical shocks and vibrations, making it suitable for earthquake-prone areas.
- Long service life: The compact and well-sealed structure reduces the likelihood of failures.

7. Intelligent Integration

Modern corrugated tanks can be integrated with various sensors to monitor parameters such as oil temperature, oil pressure, and oil level, enabling intelligent management and remote monitoring.

Advantages:
- Real-time monitoring: Sensors can continuously monitor the operating status of the transformer.
- Early fault detection: Timely identification of abnormal conditions allows for proactive maintenance.

8. Strong Environmental Adaptability

The corrugated tank can adapt to a variety of harsh environmental conditions, including high and low temperatures, humidity, and sandy environments.

Advantages:
- High weather resistance: Suitable for outdoor substations, remote areas, and extreme climates.
- Corrosion resistance: Surface treatment processes provide good corrosion resistance.

Summary

The corrugated transformer tank, with its unique corrugated structure and fully sealed design, excels in volume compensation, heat dissipation, sealing, and reliability. It also features low noise, intelligence, and strong environmental adaptability. These characteristics make it an ideal choice for modern power systems and industrial applications.
